| X86架构 | ||||
| 型号 | PVT-1600 PVT-1600-C |
PVT-1610 PVT-1610-C |
||
| CPU | AMD LX900 600MHz 32-bit x86 CPU |
Intel Atom™ N270 1.6GHz 32-bit x86 CPU |
||
| 内存 | 512KB FRAM soldered onboard 512MB DDR SDRAM SO-DIMM installed |
512KB FRAM soldered onboard 1GB DDRII SDRAM SO-DIMM installed |
||
| 存储 | 1 x CompactFlash socket 1 x 2.5" HDD bay |
1 x CompactFlash socket 1 x 2.5" HDD bay |
||
| 网络(LAN) | 2 x Realtek RTL8110SCL 10/100/1000M base-T |
2 x Realtek RTL8111B 10/100/1000M base-T |
||
| I/O接口 | 4 x isolated serial ports (4 x Full RS-232) (1x RS-422/485/CAN only for PVT-1600-C) |
4 x isolated serial ports (2 x Full RS-232, 2 x Full RS-232/422/485) (1x RS-422/485/CAN only for PVT-1610-C) |
||
| 并口 | N/A | N/A | ||
| USB接口 | 2 x USB 2.0 (Host) | 2 x USB 2.0 (Host) | ||
| VGA/DVI接口 | 1 x VGA | 1 x DVI (DVI & Analog VGA dual output) |
||
| 数字输入/输出 | 4-ch DI; 4-ch DO | 4-ch DI; 4-ch DO- | ||
| 模拟输入 | 2-ch AI | 2-ch AI | ||
| 扩展总线 | N/A | N/A | ||
| WLAN支持 | N/A | N/A | ||
| 电源 | 电源输入 | DC 9~33V | DC 9~33V | |
| 电源功耗 | 18W | 20W | ||
| 尺寸 | W×D×H(mm) | 242.5 x 44.5 x 138 mm | 242.5 x 44.5 x 138 mm | |
| 净重 | 1.9kg (4.2lb) | 1.9kg (4.2lb) | ||
| 工作温度 | -10 ~55°C | -10 ~50°C | ||
| 认证 | CCC, CE, FCC, CB | CCC, CE, FCC, CB | ||
| 操作系统支持 | Windows XP/XPe/CE.NET, Linux | Windows XP/XPe/CE.NET, Linux | ||
| 字符型LCM | Yes (Option) | Yes (Option) | ||
| 隔离I/O | Yes (Option) | Yes (Option) | ||
| CAN-BUS支持 | Yes (Option) | Yes (Option) | ||
